Product Description
Cisco Catalyst 2960-XR series switches offer power resiliency with
optional dual field-replaceable power supplies and IP Lite Cisco
IOS software with dynamic routing and Layer 3 features.
WS-C2960XR-48FPD-I is one of 2960-XR switches, IP Lite switch,
supporting forty-eight 10/100/1000 Ethernet ports with POE+ and two
10G SFP+ uplink interfaces. IP Lite Image enables basic access
layer 3 routing features, such as RIPV1, V2, OSPF stub, EIGRP stub,
HSRP, VRRP, PIM stub, etc.
WS-C2960XR-48FPD-I: Catalyst 2960-XR-L3, managed, 48 x 10/100/1000 (PoE+) + 2 x SFP+,
desktop, rack-mountable, PoE+
| Product Description | Cisco Catalyst 2960-XR-L3, managed, 48 x 10/100/1000 (PoE+) + 2 x
SFP+, desktop, rack-mountable, PoE+ |
| Enclosure Type | Rack-mountable - 1U |
| Feature Set | IP Lite |
| Ports | 48 x Ethernet 10/100/1000 Gigabit ports |
| Power Over Ethernet (PoE) | PoE+ |
| Performance | Switching capacity : 216 Gbps ¦ Forwarding performance : 130.9 Mpps |
| MAC Address Table Size | 16K (default) |
| Remote Management Protocol | CLI, HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 2c,
SNMP 3, SSH, Telnet, TFTP |
| Features | Access Control List (ACL) support, ARP support, Auto-negotiation,
Auto-uplink (auto MDI/MDI-X), Broadcast Storm Control, Cisco
EnergyWise technology, Cisco Fast EtherChannel, Cisco FlexStack
Plus, Class of Service (CoS), DHCP snooping, Dynamic ARP Inspection
(DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient
Ethernet, Hot Standby Router Protocol (HSRP) support, IGMP
snooping, Intrusion Detection System (IDS), IPv4 support, IPv6
support, Jumbo Frames support, Layer 2 switching, Layer 3 load
balancing, Link Aggregation Control Protocol (LACP), MAC Address
Notification, MLD snooping, Multicast Storm Control, Multicast VLAN
Registration (MVR), Multiple Spanning Tree Protocol (MSTP) support,
NetFlow, Per-VLAN Rapid Spanning Tree (PVRST), PoE+, Port
Aggregation Protocol (PAgP) support, Power over Ethernet (PoE),
Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning
Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support,
Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), SSH
support, Strict Priority Queuing (SPQ), Trivial File Transfer
Protocol (TFTP) support, Uni-Directional Link Detection (UDLD),
Unicast Storm Control, VLAN support |
| Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE
802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE
802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE
802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE
802.3z |
| Power | AC 120/230 V ( 50/60 Hz ) |
| Dimensions (WxDxH) | 17.5 in x 16.1 in x 1.8 in |
| Weight | 14.55 lbs |
Packaging & Shipping
CISCO Original Package + Double Carton box to Protect
Why choose us?
GPL discount for WS-C2960XR-48FPD-I can reach 70% above
FAQ
(1) Is this WS-C2960XR-48FPD-I NIB?
Yes, it is NIB and with clean serial.
(2) How long is your warranty time?
We have 1 year warranty for our new items, and 90 days warranty for
the used.
(3) If have quality issue with your WS-C2960XR-48FPD-I, how can you solve it?
If within our warranty, we can refund or replace for you.
If out of warranty, we can repair for you.
(4) How do you ship the CISCO switch WS-C2960XR-48FPD-I to me?
We cooperate with DHL, TNT, Fedex, UPS directly, not through
forwarder, so most time we can ship them faster. It always takes
1-2 days to Asia, and 2-3 days to EU & Middle East.
